NLB-R series
Feature
This product uses high-efficiency lithium-ion batteries certified by PSE, which is very suitable for use in outdoor activities at night or emergency lighting during power outages, etc.
Compared with traditional lighting such as flashlights or headlamps, the main body is made of polycarbonate (PC), making it more impact-resistant and lighter in weight.
IP65 waterproof and dustproof design, can be used in rainy or dusty environments.
NLB03/NLB06R can illuminate a wider range of light than conventional lighting such as flashlights or headlamps.
3-stage dimming (H- M- L), brightness and battery consumption can be adjusted through the three-stage dimming function (H- M- L).
The charging time is 2.5hr to achieve the goal of fast charging
Applicable
Indoor and outdoor work lights, factory machinery inspection lights, emergency lights, leisure activity lights (camping, fishing), etc.
Specification
| color temperature | 5,700K |
|---|---|
| Use temperature | -10℃～40℃ (referring to the condition without freezing) |
| protection level | IP65 |
| Body material | Polycarbonate (PC) |
| Power consumption | 3.5W / 6W |
| Charging hole | USB type-C |
| Lighting time | Maximum 12 hours |
| Dimming function | Full light (H) 1/2 (M) 1/3 (L) |
| flash function | Press and hold for 3 seconds |
| certification |
 (lithium ion battery)
|
| Basic accessories | Magnetic base |
|---|---|
| Anti-fall sling |
Standard model list
| model | Battery | Luminous flux | Illumination (0.5m) | consume electricity | Charging voltage | Charging time | Lighting time |
|---|---|---|---|---|---|---|---|
| NLB03R | rechargeable lithium-ion 3.7V/1800mAh |
360 lm | 400 lx | 3.5W | USB 5V/1A | 2.5 hr | 2 hr（H） 5 hr（M） 12 hr（L） |
| NLB06R | rechargeable lithium-ion 3.7V/3700mAh |
750 lm | 820 lx | 6W | USB 5V/2A | 2.75 hr |
Dimensional drawing
NLB-R
Dimensional drawing
| Model/size (mm) | A |
|---|---|
| NLB03R | 211.5 |
| NLB06R | 331.5 |
Basic accessories
-
Magnetic base
-
sling
